Quality Inspection System

Hwajin achieves its quality goals by operating and maintaining a quality management system (ISO 9001). We conduct product inspections with skilled human resources with many years of know-how and the latest facilities, and always maintain an optimized quality inspection system through continuous improvements.

UN Design Test and Validation

  • Drop test
    Normal temperature & low temperature

    A drop test is conducted from a Prescribed height at normal temperature and low temperature (-18℃) to inspect product damage and leakage.

  • Leakproofness test

    The test checks for air leaks by applying a prescribed air pressure over a period of time.

  • Hydrostatic test

    After filling the product with water, the prescribed water pressure is applied for a period of time to test the product for damage and leaks.

  • Stacking test
    Overlapping & multi-level stacking
    Overlapping stacking
    After the product is filled with water, it is loaded and stored at 40℃ for 28 days.
    Multi-level stacking
    After the product is filled with water, it is stacked in multiple levels at Normal temperature for 24 hours.
  • Leak test

    The product is filled with water and left for 24 hours with the inlet side down to check for leaks.

  • Assimilation test

    The product is filled with standard liquids, stored at a Prescribed temperature and duration, and inspected for quality deterioration.

Current Status of Inspection Facilities

  • Height gauges

  • Vernier calipers

  • Thickness gauges

  • Electronic scales

  • Drop testers

  • Leak testers

  • Hydraulic testers

  • Stacking testers

  • Freezers

  • Constant temperature oven

Clean System

Hwajin secures quality competitiveness through systematic process management and continuous monitoring. Using state-of-the-art equipment, we satisfy the high-quality level required by our customers.

  • Clean Room

    1000 & 100 Class Zone
    (EA/ft³ -0.5um)

  • Ultra Pure Water

    Less than 5ea/ml (100nm) Management
    of ultrapure water
    (Resistivity: over 17 MΩ)

  • Particle Measurement

    Possession of particle counter
    (Liquid/Air)

Liquid Particle Count Test

The product is filled with ultrapure water, shaken, and stabilized. A liquid particle counter is then
used to measure the number of liquid particles in the product.

UD-200L(3-Layer) CD-220L(Mono-Layer)
Size(um) Spec Size(um) Spec
0.2 Less than 10/ml 0.3 Less than 10/ml
0.3 Less than 5/ml 0.5 Less than 5/ml
CS-20L CE-20L
Size(um) Spec Size(um) Spec
0.2 Less than 9/ml 0.3 Less than 10/ml
0.3 Less than 2/ml 0.5 Less than 5/ml
CS-20LA CR-10L
Size(um) Spec Size(um) Spec
0.2 Less than 9/ml 0.3 Less than 3/ml
0.3 Less than 2/ml
CR-20L
Size(um) Spec
0.2 Less than 9/ml
0.3 Less than 2/ml

Current Status of Clean Room Inspection Facilities

  • Ultra pure water manufacturing facility

    Less than 5ea/ml (100nm)

  • Liquid particle counters

    Possession of 30nm, 100nm, and 200nm

  • Air-Borne particle counters

    Real-time monitoring device (300nm, 500nm, 5.0um: 1 count / 15 min)

    Portable device (100nm, 300nm)

  • Shakers

    Rolling shaker and stand shaker

Certification

Current Status of Certificates

  • Quality Management System
    ISO 9001

  • Designated manufacturer for
    good quality management
    on dangerous goods packaging
